Manhole Covers Designer
Cast Iron Manhole Covers for underground networks chambres acces.



1 - Mechanical drawings - Circular fitting two-piece grey cast iron manhole covers


Circular610fitting
Circular625fitting
Circular635fitting
Circular650fitting
Circular680fitting
Circular710fitting
Circular730fitting
Circular770fitting
Circular820fitting
Circular915fitting
Two-piece, circular fitting, square manhole cover Two-piece, circular fitting, circular manhole cover



2 - Mechanical drawings - Rectangular fitting two-piece grey-cast-iron drain-trap grate-covers


3 - Mechanical drawings - Rectangular one-piece grey-cast-iron drainage kerb-grates




Used shortforms :

LOD = Lid's Overall Diameter
LOH = Lid's Overall Height
FEH, (FBH)= Lid's Fitting Edge Height.
t = Lid's plate minimal thickness.
T = Lid's plate maximal thickness.

FOD = Frame's Overall Diameter (only for circular frames)
FETD, (OTD) = Frame's Exterior Top Diameter (for circular or rectangular frames, with circular top surface)

FOS = Frame's Overall Side (only for square and rectangular frames)
FETS, (OTS) = Frame's Exterior Top Side (for rectangular or circular frames with square top surface)

FOH = Frame's Overall Height
FRH, (FGH) = Frame's (fitting) Rabbet Height
FRTD, (FGTD) = Frame's (fitting) Rabbet Top Diameter
COD = Frame's Clear Opening Diameter (only for circular fit)

Note : These shortforms belong already to the public domain.



Please contact us and you will get the whole list of designs, and more details
